CT100 inverter Detailed instructions of function parameters
107
F05.09
Displayed parameters 2
when running
Setting range: 0 ～
0xFFFF
Default value:
0X0000
BIT0: torque setting (% on)
BIT1: keypad potentiometer AI0 (V on)
BIT2: analog input AI1 (V on)
BIT3: analog input AI2 (V on)
BIT4: motor overload percentage (% on)
BIT5: inverter overload percentage (% on)
BIT6～15: reserved
This parameter is used the same as F05.08. F05.08 is lower 16 bits and F05.09
is high 16 bits; when F05.08 movement judgment display is completed, F05.09
works, after F05.09 displays, automatically switch to bit0 of F05. 08.
F05.10
Displayed parameters 1
at stop
Setting range: 0 ～
0xFFFF
Default value:
0X00FF
BIT0: set frequency (Hz flickers)
BIT1: bus voltage (V on)
BIT2: input terminal status
BIT3: output terminal status
BIT4: keypad potentiometer AI0 (V on)
BIT5: analog input AI1 (V on)
BIT6: analog input AI2 (V on)
BIT7: Pulse HDI frequency (Hz on)
BIT8: PID reference (% on)
BIT9: PID feedback (% on)
BIT10: PLC and current stage of multi-step speed
BIT11: torque setting (% on)
BIT12～BIT15: reserved
This parameter is used the same as F05.08.
F05.11
Inverter rated
power
Setting range: 0.4 ～
3000.0kW
Displays the rated
power of the drive
F05.12
Inverter rated
Setting range: 0.0 ～
Displays the drive rated
