CT100 inverter Detailed instructions of function parameters
106
F05.06
Rotating speed display
correction
Setting range: 0.1 ～
999.9%
Default
value: 100.0
It is used to correct the rotating speed display. After changing the rotating speed
display correction, the displayed rotating speed = 60*running frequency *
F05.06/(motor pole number*100.0)
F05.07
Linear speed display
correction
Setting range: 0.1～999.9%
Default
value: 1.0
It is used to correct the linear speed display. After changing the linear speed
display correction, the displayed linear speed = mechanical rotating speed *
F05.07
F05.08
Displayed parameters 1
when running
Setting range: 0 ～
0xFFFF
Default value:
0X07FF
BIT0: running frequency (Hz on)
BIT1: set frequency (Hz flickers)
BIT2: bus voltage (V on)
BIT3: output current (A on)
BIT4: output voltage (V on)
BIT5: rotating speed (rpm on)
BIT6: linear speed
BIT7: output power (% on)
BIT8: output torque (% on)
BIT9: input terminal status
BIT10: output terminal status
BIT11: PID reference (% on)
BIT12: PID feedback (% on)
BIT13: Pulse HDI frequency
BIT14: Count value
BIT15: PLC and current stage of multi-step speed
You need to correspond the displayed parameters to the BIT1, and then
transform BIT0 ～ BIT15 into hexadecimal input F05.08. For example, in the
running state, if you need to monitor the running frequency, output power and
count value without other parameters displayed, transform the binary
0100000010000001 into hexadecimal 0x4081, set F05.08 to 4081.
