CT100 inverter Detailed instructions of function parameters
109
F06.08
Functions of HDI terminal
switch input
Setting range: 0～39
Default
value: 0
These parameters are used to set the function of the digital multi-function input
terminal. The functions that can be selected are shown in the following table:
Set the
value
Features
Description
0
Invalid
Please set unused terminals to be invalid to avoid
malfunction.
1
Forward running
Control the inverter operation through external
terminals.
2
Reverse running
3
Forward jogging
Please refer to description of F13.00～F13.02.
4
Reverse jogging
5
Three-wire
running
Please refer to description of F06.10.
6
Coast to stop
The inverter blocks the output immediately. The
motor coasts to stop by its mechanical inertia.
7
Fault reset
Resets faults that have occurred. It has the same
function as STOP/RST.
8
Emergency stop
Reserved
9
External fault
input
Stop the inverter and output a alarm when a fault
occurs in a peripheral device.
10
Run pause
When this terminal takes effect, inverter decelerates
to stop and save current status, such as PLC,
traverse frequency and PID. When this terminal
takes no effect, inverter restores the status before
pause.
11
Terminal UP
When the frequency is set by external terminals,
increase or decrease the reference frequency
progressively; when the frequency is set to digital
setting, the setting frequency can be adjusted up
and down; F06.11 can adjust the change rate of
UP/DOWN.
12
Terminal DOWN
13
UP/DOWN
setting clear
When the terminal is valid, it can clear the
UP/DOWN setting and restore the frequency to the
original set frequency.
14
UP/DOWN
setting cleared
temporarily
When the terminal switches on, clear the UP/DOWN
setting, restore the frequency to the frequency given
by the frequency command channel; when the
terminal switches off, return to the UP/DOWN
setting.
