CT100 inverter Function parameters
57
Function
code
Name
Detailed instruction of
parameters
Min. unit
Default
value
Modify
No.
F00.03
Auxiliary
frequency
source Y
0: keypad potentiometer AI0
1: analog input AI1
2: analog input AI2
3: HDI pulse input
4: process PID output
5: multi-step speed
6: 485 communication
1
0
○
F00.04
Reference
object of Y
frequency
source
0: relative to the max.
frequency
1: relative to frequency
source X
1
1
○
F00.05
Frequency
combination
reference
operation
0: X
1: Y
2: X+Y
3: Max (X, Y)
1
0
○
F00.06
Max. frequency
F00.07～600.00Hz
0.01Hz
50.00Hz
☆
F00.07
Upper limit
frequency
F00.08～F00.06 (Max.
frequency)
0.01Hz
50.00Hz
○
F00.08
Lower limit
frequency
0.00Hz～F00.07 (upper limit
of running frequency)
0.01Hz
0.00Hz
○
F00.09
Keypad
frequency
setting
0.00Hz～F00.06 (Max.
frequency)
0.01Hz
50.00Hz
○
F00.10
Run direction
0: positive
1: reverse
2: prohibit reverse
1
0
☆
