CT100 inverter Function parameters
70
Function
code
Name
Detailed instruction of
parameters
Min. unit
Default
value
Modify
No.
center frequency)
33: counter reset
34～39: reserved
F06.09
DI terminal filter
time
1～15
1
5
○
F06.10
Terminal control
running mode
0: two-wire control mode 1
1: two-wire control mode 2
2: three-wire control mode 1
3: three-wire control mode 2
1
0
☆
F06.11
Adjust step
length of
terminal
UP/DOWN
frequency
0.01～50.00Hz/s
0.01Hz/s
0.50Hz/s
○
F06.12
Adjust control of
keypad and
terminal
UP/DOWN
frequency
0: valid, hold on power off
1: valid, clear after power off
2: invalid
3: valid in running, clear after
power off
1
0
○
F06.13
Keypad
potentiometer
AI0 lower limit
0.00V～F06.15
0.01V
0.00V
○
F06.14
Corresponding
setting of
keypad
potentiometer
AI0 lower limit
-100.0%～100.0%
0.1%
0.0%
○
F06.15
Keypad
potentiometer
AI0 upper limit
F06.13～10.00V
0.01V
10.00V
○
