CT100 inverter Function parameters
71
Function
code
Name
Detailed instruction of
parameters
Min. unit
Default
value
Modify
No.
F06.16
Corresponding
setting of
keypad
potentiometer
AI0 upper limit
-100.0%～100.0%
0.1%
100.0%
○
F06.17
Keypad
potentiometer
AI0 filter time
0.00s～10.00s
0.01s
0.10s
○
F06.18
AI1 lower limit
0.00V～F06.20
0.01V
0.00V
○
F06.19
Corresponding
setting of AI1
lower limit
-100.0%～100.0%
0.1%
0.0%
○
F06.20
AI1 upper limit
F06.18～10.00V
0.01V
10.00V
○
F06.21
Corresponding
setting of AI1
upper limit
-100.0%～100.0%
0.1%
100.0%
○
F06.22
AI1 input filter
time
0.00s～10.00s
0.01s
0.10s
○
F06.23
AI2 lower limit
-10.00V～F06.25
0.01V
0.00V
○
F06.24
Corresponding
setting of AI2
lower limit
-100.0%～100.0%
0.1%
0.0%
○
F06.25
AI2 upper limit
F06.23～10.00V
0.01V
10.00V
○
F06.26
Corresponding
setting of AI2
upper limit
-100.0%～100.0%
0.1%
100.0%
○
F06.27
AI2 input filter
time
0.00s～10.00s
0.01s
0.10s
○
