Code Description Abbreviation
E5
Drive left-side
module
overheated
(145°C)
L-MOTOR
OVERTEMP
E6
Pump module
overheated
(145°C)
P-MOTOR
OVERTEMP
E8
Sitting sequence
error
(Engine
start>sitting>belt)
SEAT SQN
FAULT
E8
(FLAS
HING)
Safety belt switch
SEAT BELT
SW OPEN
EE Start failure
WRONG
START
EE
(FLASI
NG)
Seat switch
SEAT SW
OPEN
EL
Low battery
voltage
LOW BATT
VOLT
F0
Max. battery
voltage
MAX BATT
VOLT
F1
Min. battery
voltage
MIN BATT
VOLT
F2
Pedal trimmer
failure
ACCEL FAULT
F3
Drive right-side
module non-
saturated /
overcurrent
D-INVERTER
FAULT
F4
Drive left-side
module non-
saturated /
overcurrent
L-INVERTER
FAULT
F5
Pump module
non-saturated /
overcurrent
P-INVERTER
FAULT
F6
Drive right-side
motor current off-
set
D-MOTOR I
OFFSET
F7
Drive left-side
motor current off-
set
L-MOTOR I
OFFSET
F8
Pump motor
current off-set
P-MOTOR I
OFFSET
F9
Steering sensor
failure
STEER
SENSOR OUT
FA
12V encoder
failure
12V NOT OK
FC
Drive right-side
motor encoder
D-MOTOR
ENCODER
Fd
Drive left-side
motor encoder
L-MOTOR
ENCODER
FH 5V output failure 5V NOT OK
Code Description Abbreviation
FL
Pump input at
start up
PUMP SIGN
ON
FU
Lift neutral sensor
and lift lever
mismatch
LIFT
UNMATCH
EF
Fingertip controller
failure
EXTENSION
FAULT
L1
Lift coil open /
short
LIFT SOL
FAULT
L2
Low coil open /
short
LOW SOL
FAULT
L3
Tilt forward coil
open / short
TILT FWD
SOLFAU
L4
Tilt reverse coil
open / short
TILT BACK
SOLFAU
L5
AUX1 left coil
open / short
AUX1 L-
SOLFAU
L6
AUX1 right coil
open / short
AUX1 R-
SOLFAU
L7
AUX2 left coil
open / short
AUX2 L-
SOLFAU
L8
AUX2 right coil
open / short
AUX2 R-
SOLFAU
L9
ISO/UNLOAD coil
open / short
ISO/UNLOAD
SOL
UH
Height sensor
mismatch/separat
ed
HEIGHT
UNMATCH
21
Fingertip controller
over / low voltage
EXT VOLT
FAULT
51
Fingertip controller
CAN error
EXT TIME
FAULT
C1
Fingertip controller
current over 18A
EXT CUR
FAULT
C2
Fingertip controller
12V/5V voltage
error
EXT POWER
FAULT
FF
Fingertip knob
output error
FINGERTIP
FAULT
b1
Drive right side
controller error
DSUPERVISIO
N FLT
b2
Drive left side
controller error
LSUPERVISIO
N FLT
b3
Pump controller
error
PSUPERVISIO
N FLT
b4
Unintended
movement of right
side motor
DUNINTEND
MOVING
b5
Unintended
movement of left
side motor
LUNINTEND
MOVING
b6
Unintended
movement of
pump motor
PUNINTEND
MOVING
