D439E Service Manual 2. Engine Mechanical System (D439E)
119
Tightening torque
Description (diameter x length)
Screw size
ODxPitch (mm)
Nm kgf.m Ib-ft
Thermostat cover case flange bolt M8x1.25 21.6~32.3 2.2~3.3 16~24
Coolant temperature sensor and gauge PT 3/8 29.4~39.2 3.0~4.0 21.8~29.1
Thermostat case flange bolt(10x25) M10x1.5 35.3~52.9 3.6~5.4 26.2~39.3
Alternator adjusting plate mounting
bolt( 10x20)
- 35.3~52.9 3.6~5.4 26.2~39.3
Alternator adjusting shaft mounting nut (10) - 18.6~27.4 1.9~2.8 13.8~20.4
