D439E Service Manual 2. Engine Mechanical System (D439E)
97
Installation
1. Install the intake manifold (1).
Tightening torque : 18.6 ~ 27.4 Nm
(1.9 ~ 2.8 kgf.m, 13.8 ~ 20.4 Ib-ft)
2. Install the injection pipe (1) No. 1, 2, 3 and 4.
Tightening torque : 39.2 ~ 49 Nm
(4.0 ~ 5.0 kgf.m, 29.1 ~ 36.4 Ib-ft)
