Doosan D55C-5 Service Manual

D439E Service Manual 5. Service Tool
228
CAUTION
<Figure 3: Connecting the main DLC to G-scan>
Connecting the main DLC connector to G-scan, tighten the 3 clamping screws to the body of G-scan
firmly.
<Figure 4: Caution for carrying G-scan>
Carrying G-scan, do not hold the DLC cable. Hold the main module or hand strap.

Doosan D55C-5 Specifications

General

Brand	Doosan
Model	D55C-5
Category	Engine
Language	English
