D439E Service Manual 5. Service Tool
258
Operating Sequence and Reference
Processing of fault Code Searching
Select
in the main screen after completing system selection, and it will show fault
codes of selected systems as below.
<Figure 2: processing of fault Code Searching>
Move to DTC Analysis or Data Analysis
1. Using the stylus pen or
buttons, select the detected DTC.
2. Select the diagnosis mode.
or
Move to DTC Analysis of selected system
or
Move to Data Analysis of selected system
To Next Page
