D439E Service Manual 5. Service Tool
269
Introduction of Data Analysis
<Figure 1: Data Analysis Screen>
Fixes the selected item at the top of the screen.
Splits the current data screen into left and right sides and shows maximum 26 data.
Shows the current data in graph mode.
Starts recording the selected items.
Dual mode and other functions available.
NOTE
• If the wanted data is not on display, move the scroll bar with the stylus pen or use
,
buttons to find it.
• If you want to return to initial screen, select the
on top right of the screen or button.
To Next Page
