D439E Service Manual 5. Service Tool
271
Full
• Display maximum item number of current data on screen. On the Data Analysis screen, select
or button, then the screen will be divided as shown in <Figure 3> and
maximum 26 data items are shown.
<Figure 3: See in Full>
• Return to Normal screen.
On Full screen mode, press
or button.
NOTE
• On the screen in Full mode, FIX and graph functions are not available.
• Find wanted data moving the scroll bar with the stylus pen or use the control navigation.
• If full name of data item is not shown, select the item using the stylus pen, then full name can be shown by
moving to left side.
