D439E Service Manual 2. Engine Mechanical System (D439E)
37
CAUTION
Before removing the timing gear case, remove
timing gear case mounting bolt (1) at the supply
pump first.
If the mounting bolt at the supply pump is not
removed, timing gear case will not be removed.
8. Remove the front oil seal slinger (1).
9. Remove the oil pump gear (1).
10. Remove the idler gear A (1).
To Next Page
