D439E Service Manual 2. Engine Mechanical System (D439E)
62
Valve and cylinder head Assembly
1. Install the water director to the cylinder head.
2. Install the intake and exhaust valve.
3. Apply the engine oil on the valve stem seal lip and
install the valve stem seal using the special tool
(09222-45100).
NOTE : Tap the seal until the special tool (09222-
45100) contacts the cylinder head.
CAUTION
When installing the valve stem seal (1), use the
new one.
To Next Page
