Instructions for use Isolette 8000 plus SW 5.n 135
Reprocessing
CAUTION
Risk of injury or damage to the device
Liquid in the collection bottle can contain patient fluids.
► Collection bottles and fluids should be handled according to hospital guidelines.
4 Lift the latches on the side of the water reservoir (H) and remove the humidifier
(I) from the humidifier chamber.
12.1.8 Removing the hand port gaskets, hose grommets, and iris port
sleeves (if installed)
1 Pull the hand port gaskets (A) from all sides of the hood to remove them.
2 Pull the hose grommets (B) from each side of the hood to remove them.
3 If equipped with the optional iris ports on the side access panels, remove the
disposable iris port sleeves from the retainer rings.
4 Wipe the retainer rings clean.
5 Discard disposable sleeves.
080
H
I
H
081
A
B
