Instructions for use Isolette 8000 plus SW 5.n 145
Reprocessing
B Fold back, and slip the larger elastic band over the outer ring of the port
housing.
C To close, rotate the outer ring (A). If properly installed, the sleeve opens
again when rotation is reversed.
14 Install the hose grommets into the front and rear edges of each side of the hood.
Replace hose grommets if distorted or torn.
15 Install a hand port gasket on each hand port. Orient each gasket so that the 2
tabs on the gasket are on the hinge side of the door opening (B) and the single
tab is on the latch side of the door opening (C).
087088090
