Instructions for use Isolette 8000 plus SW 5.n 51
Assembly and preparation
4 Place the scale (A) in the incubator on the bed (B).
5 Ensure that the bed is level and not in the Trendelenburg or Reverse
Trendelenburg position.
6 Determine if leveling is required by checking the level indicator (C).
7 If necessary, remove the 2 level-adjuster plugs. Then fine-tune the 2 level
adjusters (D) on the scale until the bubble on the level indicator is within the
circle. For right or left level adjustments, use the right-hand or left-hand bed-tilt
knob. Reinstall plugs.
8 Replace the mattress.
9 Connect the scale cable to the weight connector on the sensor module
assembly (see Sensor Module on page 31).
WARNING
Risk of death or serious injury
Infant could become entangled with cables and be injured.
► Use cable management clips.
003004
