78 Instructions for use Isolette 8000 plus SW 5.n
Operation
8.1.1 Air temperature mode
To select the air temperature control set point:
1 If necessary, unlock the keypad.
2 At display 1, press the Air button (A) to select the air temperature mode.
If no keys are pressed within 15 seconds of making any selection, the screen
automatically reverts to the previous display.
 The screen changes to the temperature display with new button labels and a
border around the current temperature set point.
3 Set the air temperature to the prescribed setting.
 To raise the set temperature in 0.1° increments, press the Up Arrow key (A).
 To lower the set temperature in 0.1° decrements, press the Down Arrow key
(B).
4 Press the Home button (C) and confirm the air set temperature setting.
 Device returns to display 1.
5 Press the Keypad Lock (D) key.
✓ Keypad is locked.
023052
A
40
35
30
25
20
A
B
C
D
