EL7.5 - EL12.5 (S - SS) User manual - ENG 16/70
2.1.1 Pump plate position
See Fig. 2 for the position of the machine identification plate.
Fig. 2
The electric data AMP (current absorbment)
and HP/KW (power) indicate the maximum
values. Never exceed these values during
continuous operation.
The electric data VOLT (voltage) indicates a
nominal value. Never exceed a 10% variation
of these value during continuous operation.
2.1.2 Dimensions and weight
Refer to the data-sheet of the pump (see chapter Attachments) for overall
dimensions and weight.
2.1.3 Technical specifications
Refer to the data-sheet of the pump (see chapter Attachments) for any technical
specifications (performance, materials, plate data).
