EL7.5 - EL12.5 (S - SS) User manual - ENG 32/70
- lifting equipment
Fig. 16
See carefully the machine weight on the data
plate for correct choosing of any lifting
equipment.
5.1.2 Bolts tightening torque
See below the suggested tightening torque T
S
for most common bolts size:
Tab. 2
