EL7.5 - EL12.5 (S - SS) User manual - ENG 67/70
7.4 Water sensor
Not available
7.5 Cooling jacket
Not available
7.6 Cutter knife
The cutter knife is a optional device installed on the main shaft and replacing the
connector. Its purpose is to cut and minimize the dimension of some kind of solids
(tipically soft/fibrous wood pieces, seaweed and similar).
7.6.1 Spare parts
Fig. 44
POS.
Q.TY
PART NUMBER
DESCRIPTION
REPLACE POS./NR.
6A1
1
F39201 (*)
CUTTER KNIFE
11 / F21204
