EL7.5 - EL12.5 (S - SS) User manual - ENG 63/70
POS.
Q.TY
PART NUMBER
DESCRIPTION
See…
125
1
F21210V01 (*)
CABLE RUBBER SLEEVE
Fig. 32
126
3
F21212 (*)
STEEL WASHER
Fig. 32
127
3
F21211 (*)
RUBBER WASHER
Fig. 32
129
1
A3012073
TERMINAL BOARD
Fig. 33
130
1
A3004063 (*)
POWER CABLE (default 20 m)
Fig. 31
131
1
A9031043 (*)
CABLE RESIN CASTING
Fig. 33
141
3
A2517002
EYEBOLT
Fig. 31
142
1
A3005165 (*)
CABLE GLAND
Fig. 33
142A
1
A9058321(*)
MASTIC
Fig. 33
143
2
A2019023
SPRING WASHER
Fig. 34
144
1
A6038045
CABLE CLIP
Fig. 32
170
1
A6504065
PLUG
Fig. 35
171
1
F39291
PLUG
Fig. 31
180
1
A1504019
COPPER WASHER
Fig. 35
200
12
A2501005
BOLT TE M10x30
-
201
4
A2501013
BOLT TE M10x40
-
202
10
A2501014
BOLT TE M12x30
-
203
4
A2501009
BOLT TE M8x16
-
204
4
A2501018
BOLT TE M12x50
-
205
3
A2501016
BOLT TE M12x40
-
206
3
A2501049
BOLT TE M12x45
-
207
3
A2501004
BOLT TE M12x25
-
250
4
A2502001
BOLT TCEI M6x10
-
251
2
A2502015
BOLT TCEI M6x20
-
252
2
A2502088
BOLT TCEI M6x35
-
300
7
A2510003
WASHER M12
-
301
4
A2510001
WASHER M8
-
302
3
A2510018
WASHER M6
-
350
12
A2527016
SEAL WASHER M10
-
351
16
A2527018
SEAL WASHER M12
-
400
4
A2508005
NUT M10
-
401
3
A2508012
NUT M12
-
402
12
A2508009
NUT M6
-
503
1
A2518005
KEY
Fig. 39
602
3
SEE POS. 129
TERMINAL BOARD PLATE
Fig. 33
6.2.5 Suggested spare parts
Dredging pumps are equipment for abrasive and heavy jobs. These kinds of
applications naturally wear the consumable parts of the machine. The wearing of the
consumable parts will get the performance of the machine lower in terms of
production and safeguard. The manufacturer suggests to keep ready at worksite or
workshop the safety parts highlighted in the spares list with the symbol (*).
