DRAGFLOW EL7.5 - Common Parts List

DRAGFLOW S.r.l. - Sede legale: Via Satiro, 11 – 37121 VERONA Italy
Sede amm.: Via Paesa – 46048 ROVERBELLA (MN) Italy ● Tel. +39 0376 1685400
Fax +39 0376 1685499 - Cod. Fisc e P. IVA : IT 02757460239 – R.E.A. Verona n. 280092
Registro Impr. Di Verona n. 189595/1997 Capitale Sociale € 10.400 interamente versato
EL7.5 - EL12.5 (S - SS) User manual - ENG 62/70
6.2.4 Common parts list
POS.
Q.TY
PART NUMBER
DESCRIPTION
See…
4
1
F39285V01 (*)
CASING-OIL CHAMBER
Fig. 35
6
1
F21292 (*)
UPPER WEAR PLATE
Fig. 36
7
1
F21197 (*)
LOWER WEAR PLATE
Fig. 39
10
1
A7503053 (*)
AGITATOR
Fig. 40
11
1
F21204 (*)
AGITATOR CONNECTOR
Fig. 40
12
1
A2508027 (*)
AGITATOR NUT
Fig. 40
13
1
F21215 (*)
AGITATOR SPACER
Fig. 40
21
1
F39289
LOWER SEALS HOUSING
Fig. 36
Fig. 38
23
1
F21207V02 (*)
LOWER SHAFT SLEEVE
Fig. 36
Fig. 38
30
1
F21208
UPPER BEARINGS FLANGE
Fig. 34
33
1
F24506
SPRING SPACER
Fig. 34
34
1
F21201
UPPER SUPPORT
Fig. 32
40
1
F21202
UPPER INSPECTION COVER
Fig. 32
45
1
F21209
POWER CABLE GLAND
Fig. 32
50
1
G21214 (*)
STRAINER
Fig. 40
51
1
F21213 (*)
DISCHARGE ADAPTER
Fig. 31
61
2
F39288 (*)
SEAL
Fig. 36
Fig. 38
62
2
A6503030 (*)
SEAL
Fig. 36
Fig. 38
77
1
A1507124 (*)
MECHANICAL SEAL
Fig. 36
Fig. 37
80
1
A1003011 (*)
THRUST BEARING 51210
Fig. 34
81
1
A1001107 (*)
BALL BEARING 6310 2RS
Fig. 34
82
1
A1001101 (*)
BALL BEARING 6308 2RS
Fig. 34
90
1
A1501110VITON (*)
O-RING
Fig. 39
91
1
A1501116VITON (*)
O-RING
Fig. 36
92
2
A1501120VITON (*)
O-RING
Fig. 31
Fig. 35
93
1
A1501129VITON (*)
O-RING
Fig. 35
94
1
A1501119VITON (*)
O-RING
Fig. 32
105
2
A1501037VITON (*)
O-RING
Fig. 36
Fig. 38
110
1
A1501117VITON (*)
O-RING
Fig. 36
Fig. 38
