EL7.5 - EL12.5 (S - SS) User manual - ENG 61/70
6.2 Spare parts list
6.2.1 Specific parts list for EL7.5 - EL7.5S - EL7.5SS
POS.
Q.TY
PART NUMBER
DESCRIPTION
See…
1
1
F21198 (*)
IMPELLER (50 Hz)
Fig. 39
1
1
F39209 (*)
IMPELLER (60 Hz)
Fig. 39
2
1
RR0001013
MAIN SHAFT + ROTOR (EL7.5)
Fig. 34
2
1
RR0001014
MAIN SHAFT + ROTOR (EL7.5S)
Fig. 34
2
1
RR0001016
MAIN SHAFT + ROTOR (EL7.5SS)
Fig. 34
3
1
RR0001012
MOTOR HOUSING + STATOR (EL7.5)
Fig. 31
3
1
RR0001015
MOTOR HOUSING + STATOR (EL7.5S)
Fig. 31
3
1
RR0001017
MOTOR HOUSING + STATOR (EL7.5SS)
Fig. 31
6.2.2 Specific parts list for EL10 - EL10S - EL10SS
POS.
Q.TY
PART NUMBER
DESCRIPTION
See…
1
1
F21199 (*)
IMPELLER (50 Hz)
Fig. 39
1
1
F39210 (*)
IMPELLER (60 Hz)
Fig. 39
2
1
RR0001014
MAIN SHAFT + ROTOR (EL10)
Fig. 34
2
1
RR0001016
MAIN SHAFT + ROTOR (EL10S)
Fig. 34
2
1
RR0001018
MAIN SHAFT + ROTOR (EL10SS)
Fig. 34
3
1
RR0001015
MOTOR HOUSING + STATOR (EL10)
Fig. 31
3
1
RR0001017
MOTOR HOUSING + STATOR (EL10S)
Fig. 31
3
1
RR0001019
MOTOR HOUSING + STATOR (EL10SS)
Fig. 31
6.2.3 Specific parts list for EL12.5 - EL12.5S - EL12.5SS
POS.
Q.TY
PART NUMBER
DESCRIPTION
See…
1
1
F21200 (*)
IMPELLER (50 Hz)
Fig. 39
1
1
F21198 (*)
IMPELLER (60 Hz)
Fig. 39
2
1
RR0001016
MAIN SHAFT + ROTOR (EL12.5)
Fig. 34
2
1
RR0001018
MAIN SHAFT + ROTOR (EL12.5S)
Fig. 34
2
1
RR0001020
MAIN SHAFT + ROTOR (EL12.5SS)
Fig. 34
3
1
RR0001017
MOTOR HOUSING + STATOR (EL12.5)
Fig. 31
3
1
RR0001019
MOTOR HOUSING + STATOR (EL12.5S)
Fig. 31
3
1
RR0001021
MOTOR HOUSING + STATOR (EL12.5SS)
Fig. 31
