Dranetz Xplorer User Manual

17
The single fuse voltage adapter kit is used for one
single voltage measurement input, while the four fuse
voltage adapter kit is used for a three phase and
neutral voltage measurement inputs.
Wire Markers Each kit consisting of snap-on wire markers in various
colors is supplied as described in the following table.
These wire markers are to be used to identify each
wire connection applicable to your installation.
 WMV-KIT (118376-G1) measures 0.138 inch
diameter; kit is included with the standard
measurement cable set and used for identifying
voltage cables.
 WMI-KIT (118377-G1) measures 0.218 inch
diameter; kit is included with the standard
measurement cable set and is used for identifying
current probes.
 WMFV-KIT (118376-G2) measures 0.138 inch
diameter; kit is supplied with each Fuse Voltage
Adapter and is used for identifying voltage cables.
Wire Marker Color WMV-KIT
Quantity
WMI-KIT
Quantity
WMFV-KIT
Quantity
Blue 16 4 4
Black 4 4 4
Brown 4 4 4
Orange 4 4 4
Yellow 4 4 4
Red 4 4 4
Green 4 4 4
White 16 4 4
