Draytek Vigor167 User Manual

2
Interface
Explanation
PWR Connecter for a power adapter.
ON/OFF ON/OFF: Power switch.
Factory Reset Restore the default settings. Usage: Turn on the modem.
Press the button and keep it for more than 10 seconds. Then
the modem will restart with the factory default configuration.
P2-P1 Connecter for local networked devices.
DSL Connecter for accessing the Internet through xDSL.

Note
Remove the protective film from the router before use to ensure ventilation.

Draytek Vigor167 Specifications

General

VDSL	Yes
Interface	RJ-45, RJ-11
Modem speed	30000 Kbit/s
Antenna type	Internal
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	0 - 45 %
DC input voltage	12 V
Power consumption (typical)	4.4 W
Routing protocols	IP

Weight and Dimensions

Depth	181 mm
Width	40 mm
Height	125 mm
Weight	270 g
