Draytek Vigor167 User Manual

60
members within the multicast group. When Fast Leave is enabled,
multicast for a group is immediately terminated when the last host in
that group sends a “leave” message.
Apply Save the current settings and exit the page.
After finishing this web page configuration, please click Apply to save the settings.
II-2-6-2 IGMP Status
Displays a list of active multicast groups.
Item Description
Group ID ID port of the multicast group, which is within the IP range reserved
for IGMP, 224.0.0.0 through 239.255.255.254.
P1 to P2 LAN ports that have IGMP hosts joined to this multicast group.
II-2-7 Objects
II-2-7-1 IP Object
For IPs in a range and service ports in a limited range usually will be applied in configuring router’s
settings, therefore we can define them with objects and bind them with groups for using
conveniently. Later, we can select that object/group for applying it. For example, all the IPs in the
same department can be defined with an IP object (a range of IP address).

Draytek Vigor167 Specifications

General

VDSL	Yes
Interface	RJ-45, RJ-11
Modem speed	30000 Kbit/s
Antenna type	Internal
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	0 - 45 %
DC input voltage	12 V
Power consumption (typical)	4.4 W
Routing protocols	IP

Weight and Dimensions

Depth	181 mm
Width	40 mm
Height	125 mm
Weight	270 g
