Draytek Vigor167 User Manual

32

Note:
Switch these two icons by click the mouse cursor on them.
- means “Enable”.
- means “Disable”.
II-2-2 WAN
When the operation mode is configured as Router Mode, the Configuration>>WAN page will be
shown as the following page.
II-2-2-1 WAN Connections
This page is to configure the general settings for WAN connection.
Available settings are explained as follows:
Item Description
Name Displays the name of the interface.
Physical Interface Displays the physical mode (e.g., ADSL, VDSL, and etc.) used by the
WAN interface.
IPv4 Connection Type Displays the connection type (e.g., PPPoE, DHCP, and etc.).
IPv4 Address Displays the IP address used by the WAN interface.
IPv4 Primary DNS Displays the primary DNS server address.
Option Edit - Click to modify the interface name and physical mode.
To configure the detailed settings for the selected WAN interface, click the Edit link to the right side
of the WAN interface.

Draytek Vigor167 Specifications

General

VDSL	Yes
Interface	RJ-45, RJ-11
Modem speed	30000 Kbit/s
Antenna type	Internal
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	0 - 45 %
DC input voltage	12 V
Power consumption (typical)	4.4 W
Routing protocols	IP

Weight and Dimensions

Depth	181 mm
Width	40 mm
Height	125 mm
Weight	270 g
