Draytek Vigor167 User Manual

81
III-1-2-2 TR-069
Vigor device supports the TR-069 standard for remote management of customer-premises
equipment (CPE) through an Auto Configuration Server, such as VigorACS.
Available settings are explained as follows:
Item Description
TR-069 Switch the toggle to enable or disable the function.
ACS Server
ACS Server On Choose the interface for connecting the router to the Auto
Configuration Server.
URL Enter the URL for connecting to the ACS.
Wizard - Click it to enter the IP address of VigorACS server, port
number and the handler.
Username/Password Enter the credentials required to connect to the ACS server.
Event Code Use the drop down menu to specify an event to perform the test.
Test With Inform - Click it to send a message based on the event
code selection to test if such CPE is able to communicate with
VigorACS server.
Last Inform Response
Time
Display the time that VigorACS server made a response while
receiving Inform message from CPE last time.
More settings
CPE Client This section specifies the settings of the CPE Client.
Protocol - Select Https if the connection is encrypted; otherwise select
Http.
Port - In the event of port conflicts, change the port number of the
CPE.
Username / Password - Enter the username and password that the
VigorACS will use to connect to the CPE.
Periodic Inform Enable / Disable - Switch the toggle to enable or disable the function.

Draytek Vigor167 Specifications

General

VDSL	Yes
Interface	RJ-45, RJ-11
Modem speed	30000 Kbit/s
Antenna type	Internal
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	0 - 45 %
DC input voltage	12 V
Power consumption (typical)	4.4 W
Routing protocols	IP

Weight and Dimensions

Depth	181 mm
Width	40 mm
Height	125 mm
Weight	270 g
