Draytek Vigor167 User Manual

22
II-1-4 Routing
Static routing is an alternative to dynamic routing. It is a process that the system network
administrator can configure network routers with all the required information for packet
forwarding.
Open Configuration >> Routing.
To add a new IPv4 static route, click the +Add link to get the following page.
Available settings are explained as follows:
Item Description
Name Enter a name as the profile name.

Draytek Vigor167 Specifications

General

VDSL	Yes
Interface	RJ-45, RJ-11
Modem speed	30000 Kbit/s
Antenna type	Internal
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	0 - 45 %
DC input voltage	12 V
Power consumption (typical)	4.4 W
Routing protocols	IP

Weight and Dimensions

Depth	181 mm
Width	40 mm
Height	125 mm
Weight	270 g
