50
II-2-4-2 RIP
The Routing Information Protocol (RIP) is the most popular interior routing protocol used by a
router.
Available settings are explained as follows:
Item Description
Enabled When Enabled, the router will attempt to exchange routing
information with neighbouring routers using the Routing Information
Protocol.
RIP Version Specify the version number (V1/V2) for RIP protocol.
Enabled Networks +Add - Specify an interface (LAN/WAN) for applying the RIP.
Timers
Update Timer Enter a value as the update timer.
When the time is up, the Vigor router will send a message containing
the complete routing table to all neighboring routers for exchanging
the routing information.
Timeout Timer The routing information will be valid (but not removed) till the time
expiration set in this field.
The information will be kept in the routing table temporarily. At the
same time, the neighbors will be notified that the route has been
dropped.
Garbage Timer The route will be removed from the routing table upon the expiration
set in Garbage Timer.
Redistribute
Connected Redistribute connected routes into the RIP tables.
Kernel Redistribute kernel routes into the RIP tables.
Apply Save the current settings and exit the page.
After finishing this web page configuration, please click Apply to save the settings.
