Draytek Vigor167 User Manual

54
II-2-5-2 DMZ
Vigor router provides a facility DMZ Host that maps ALL unsolicited data on any protocol to a single
host in the LAN. Regular web surfing and other such Internet activities from other clients will
continue to work without inappropriate interruption. DMZ Host allows a defined internal user to be
totally exposed to the Internet, which usually helps some special applications such as Netmeeting or
Internet Games etc.
To add a new DMZ profile, click the +Add link to get the following page.
Available settings are explained as follows:
Item Description

Draytek Vigor167 Specifications

General

VDSL	Yes
Interface	RJ-45, RJ-11
Modem speed	30000 Kbit/s
Antenna type	Internal
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	0 - 45 %
DC input voltage	12 V
Power consumption (typical)	4.4 W
Routing protocols	IP

Weight and Dimensions

Depth	181 mm
Width	40 mm
Height	125 mm
Weight	270 g
