1-2
Chapter 1 Before Operation
2-2. Accessories
[1] [2] [3] [4]
[5] [6] [7] [8] [9]
No. Name QTY Function
DF-980 DF-970
[1] Cross fold lever 1 (*1) For holding down the folded paper when cross fold.
[2] Auxiliary paper ejection guide 1 1 Attached to the stacker roller at the ejecting section.
[3] Folding plate 1 1 1 Attached to the upper right section on the operating
side.
[4] Folding plate 2 1 1 Attached to the bottom left section on the operating
side.
[5] T-handle hexagonal wrench 1 (*1) Used when moving the auxiliary paper feed ring.
Do not use the T-handle hexagonal wrench for a
purpose other than handling the auxiliary paper
feed ring as instructed in this manual.
[6] Scale label 1 1 Used to measure non-standard size paper. Attach the
scale.
[7] Instruction manual 1 1 This manual
[8] Power cord 1 1 Applicable for 220 to 240 V
[9] Power cord 1 1 Applicable for 120 V
(*1) Provided as an option for the DF-970.
