1-16
Chapter 1 Before Operation
5-3. Stopper adjust screen
A4 +0.0/
- +
+ -
A4 +0.0/+0.0
[A] [B]
Screen Item Display Details
[A] Folding plate 1 stopper correction ** * : Settings (-5.0 to 5.0/-0.20 to 0.20)
[B] Folding plate 2 stopper correction
5-4. Operation on the menu screen
The basic operation on the menu screen is as follows. Here how to open [Paper size setting] window is
explained as an example.
Paper Size Set
Set
Auto
P Length 457.0
1
Press Menu while the top screen is
displayed.
A setting window will be displayed.
2
Press the key or key to select
[setting].
Paper Size Set
Set
Auto
P Length 457.0
3
Press the key.
The item can be changed.
Paper Size Set
Set
Man
P Length 457.0
4
Press the key or key to select
[setting].
5
Press the key.
The selected details are set.
457 +0.0/
Ready
0
6
Press the key.
Returns to the top screen.
To Next Page
