1-17
Chapter 1 Before Operation
5-5. Classication of buzzer sounds
In this machine the buzzer sounds in conrmation when setting on the control panel or paper runs out on
the paper feed tray. Classication of the sounds is as follows.
pi” : Operational sound at the time of normal key operation
pipi” : Warning alarm at the time of mis-operation, mis-feed of paper, or paper empty
pii” : At the start of folding operation or end of normal folding operation
In conrmation of change of various settings
piipii” : At the occurrence of an error such as paper jam
piipiipii” : At the occurrence of an error to be asked for Duplo dealers assistance
6. Paper Types and Sizes
Paper type
Fine quality paper : 52.3 to 157 g/m
2
/14 to 40 lb
Rough paper, Stencil paper, Recycle paper, Specic art paper, Specic coated paper
Paper size
Standard Paper (The standard paper can be used only when it is stacked in the machine direction.)
Paper
size
L × W
(mm)
Paper
size
L × W
(mm)
Paper
size
L × W
(inches)
A3 420 x 297 B4 364 x 257 LGR 17 x 11
A4 297 x 210 B5 257 x 182 LGL 14.0 x 8.5
A5 210 x 148 B6 182 x 128 LTR 11.0 x 8.5
INV 8.5 x 7
STMT 8.5 x 5.5
Paper feed
direction
Paper
Length : 105 to 457.2
4.13 to 18.0
Width : 74 to 311/
2.91 to 12.24
Unit : mm/inches
Non-standard paper
Width : 74 to 311 mm/2.91 to 12.24 inches
Length : 105 to 457.2 mm/4.13 to 18.0 inches
* The aspect ratio for non-standard paper is
1:1 to 2.2:1.
Some limitations in setting and paper quality
may be applied depending on paper size.
The A6, A7, or B7 paper can be used as non-
standard paper.
Paper that cannot be used with this machine
Paper out of specications
Curled paper
Wavy paper
