4-4
Chapter 4 Using Options
1-3. Placing the cross fold guide
When the DF HAND FEED KIT is attached, the
location to store the cross fold lever will be
changed. Insert the cross fold lever into the
pillar of the sensor cover to store the lever in
the direction as shown in the gure.
Be sure to store the cross fold lever at
the specied place and in the specied
direction. By moving during operation
of this machine the folding roller may be
damaged, resulting in malfunction.
Open or close the top cover
gently.
Hands or ngers may be caught in the
cover section. Doing so may result in
injury.
1-4. Operation
Do not put ngers inside during operation.
Keep away long hair, ties, jewelry and loose clothing.
It could cause injury.
1
Remove the auxiliary paper ejection
guide from the paper receiving tray.
2
Open the paper receiving tray to
the right side when it is seen on the
operating side.
3
Attach the auxiliary paper ejection
guide to the stacker roller.
To Next Page
