1-19
Chapter 1 Before Operation
8. Options
8-1. DF HAND FEED KIT (Only for EU)
[1] [2]
No. Name Function
[1] Hand feed tray Insertion inlet for feeding paper manually to fold.
[2] Auxiliary feed guide Subordinately guides sheets so that the may be fed properly.
8-2. DF GUIDE UNIT
[1]
No. Name Function
[1] Auxiliary paper feed guide For holding down the edges of large sheets of paper
8-3. DF CROSS FOLD UNIT (DF-970)
[1] [2]
No. Name Function
[1] Cross fold lever For holding down the folded paper when cross fold.
[2] T-handle hexagonal wrench Used when moving the auxiliary paper feed ring. Do not use the T-handle
hexagonal wrench for a purpose other than handling the auxiliary paper feed
ring as instructed in this manual.
