3-23
Chapter 3 Advanced Operation
6. Changing the Stacker Roller Height
Some thick and sti paper may not be ejected smoothly because the paper may open after folding.
Change the stacker roller height and widen the space for the paper to pass in ejection.
1
Remove the auxiliary paper ejection guide.
2
Lift the stacker roller and hold it with hand to move to the [A] position shown in the
gure.
[A]
After completing folding operations, be sure to return the stacker roller to the standard
position. Leaving it in the raised state will result in poor alignment of ejected paper.
7. Stacking the Folded Paper
The angle of the paper receiving tray of this machine can be changed. If the angle is changed, the folded
paper can be stacked in the following two ways according to the purpose.
Straight stacking Diagonally stacking
To Next Page
