1-5
Chapter 1 Before Operation
8
Insert the folding plate 1 into the main body of the machine along with the set guide.
Attach the folding plate 1 holding with both hands.
Check that the gear on the reverse side of the folding plate 1 rotates in the front-back direction, if it is
not easy to attach the folding plate 1.
Attach the folding plate 1 to this machine after rotating the gear by 360 degree in a rotating direction,
when it does not rotate either in the front direction or in the back direction.
9
Open the top cover.
Open or close the top cover
gently.
Hands or ngers may be caught in the
cover section. Doing so may result in
injury.
10
Rotate the jam correction handle to
check that the folding roller rotates
smoothly.
11
Place the cross fold lever as shown in
the gure.
(Provided as an option for the DF-970.)
Be sure to store the cross fold lever at
the specied place and in the specied
direction. By moving during operation
of this machine the folding roller may be
damaged, resulting in malfunction.
12
Close the top cover.
To Next Page
