4-23
CHAPTER 4 FINE-ADJUSTMENT AND OPTION SETTING
3-9. Setting the Receiving Tray ON/OFF
Select whether you use the receiving tray.
Default setting: ON
1.
Press the next or previous button on the option screen to display the screen
below.
2.
Press the ON/OFF button.
3
Receiving Tray
ON/OFF
ON/OFF
Button
Previous Button
Next Button
When you switch from ON to OFF, the following screen appears. If you press "Yes," the movable
stacker will be pushed forward (operator's side).
After checking that the receiving tray
is not attached to the machine, press
"Yes."
If you switch from OFF to ON, the movable stacker will be pushed backward (non-operator's
side).
Chapter 2 "Preparing for Operation" "3-4. Replacing the Receiving Tray with the Stacker
Stopper" ( p.2-9)
Chapter 2 "Preparing for Operation" "3-5. Replacing the Stacker Stopper with the Receiving
Tray" ( p.2-10)
3.
Press the next or previous button to display other option screen.
To Next Page
