4-28
CHAPTER 4 FINE-ADJUSTMENT AND OPTION SETTING
3-14. Setting Opening Amount of Clamp (for Variable Mode)
Specify the opening amount of the movable clamp when the book block thickness is set to the variable
mode. After each booklet is discharged or when the movable clamp button is pressed, the clamp will
open to the specified amount.
Setting range: 5.0 mm (0.2 inch) to fully open (approx. 60 mm/2.36 inches)
Default setting:
1.
Press the next or previous button on the option screen to display the screen
below.
30.00
15.00
Clamp opening
amount (for variable
mode)
Previous Button Next Button
Example
2.
Press or to specify a value.
Each time you press the button, the value will change by 5.0 mm (0.2 inch).
3.
Press the next or previous button to display other option screen.
To Next Page
