CHAPTER 2 PREPARING FOR OPERATION
4.
Pull out the milling adjustment bar
from the hole and put it back to its
original place.
3-2. Glue Tank
The position of the side glue rollers need to be changed depending on whether binding a book block
with a cover or without a cover.
1.
Loosen the screws (3) using the
supplied wrench (opposite side
distance 3 mm).
Side glue roller
adjustment
Spanner
2.
Turn the side glue roller adjustment
using the supplied spanner to adjust
the position of the side glue rollers.
The iron spanner gets hot. Do not
continue to use it for a long time.
