4-27
CHAPTER 4 FINE-ADJUSTMENT AND OPTION SETTING
3-13. Setting Opening Amount of Clamp (for Normal Mode)
Specify the opening amount of the movable clamp when the book block thickness is set to the normal
mode. After each booklet is discharged or when the movable clamp button is pressed, the clamp will
open to the specified amount + book block thickness.
Example:
When you specify 10.0 mm (0.39 inch) here and the book block thickness after a size change is 5.0
mm (0.2 inch), the clamp will open by 15.0 mm (0.59 inch).
Setting range: 5.0 mm (0.2 inch) to fully open (approx. 60 mm/2.36 inches)
Default setting: 10.0 mm (0.39 inch)
1.
Press the next or previous button on the option screen to display the screen
below.
30.00
15.00
Clamp opening
amount (for normal
mode)
Previous Button Next Button
Example
2.
Press or to specify a value.
Each time you press the button, the value will change by 5.0 mm (0.2 inch).
3.
Press the next or previous button to display other option screen.
To Next Page
