Duplo DPB-500 User Manual

3-21
CHAPTER 3 STARTING BINDING OPERATION
6. Finishing Binding
Once a binding operation is complete, check if there is enough hot melt glue left in the glue tank. If the
surface of the glue on the application drums is lumpy, you need to add hot melt glue to the glue tank.
Be careful not to boil dry the glue tank.
● High voltage of electricity supplied to the glue tank may cause an electric shock. Be
careful.
● The temperature around the glue tank is very high. Be careful when you add hot melt
glue.
Main cover
1.
Open the main cover.
2.
Check the remaining amount of the
hot melt glue.
Hot melt
The groove is the upper limit
for hot melt
Groove
Glue tank
3.
Add hot melt glue to the glue tank if
necessary.
4.
Close the main cover.
Be careful not to get your hand caught
when you close the main cover.
