CHAPTER 1 BEFORE OPERATION
3-2. Milling Section
Milling Adjustment Label
Refer to the label when
adjusting the height of the level
plate using the milling
adjustment bar.
Milling Adjustment Bar
Use this bar to adjust the
milling depth.
Level Plate
To change the milling depth, move up or down
the level plate.
Milling Guide
This guide prevents paper chips from
scattering. The guide moves automatically
according to the thickness of the book block.
