Duplo DPB-500 User Manual

2-20
CHAPTER 2 PREPARING FOR OPERATION
2.
For side base
Return Button
Cancel Button
Clear
Button
190. 0
The range you can input
Input the length between the scoring
position and cover edge using the
numeric keypad.
The range you can input will be displayed
on the lower right of the screen. Press the
cancel button or clear button, then input an
appropriate value.
Cover width: 250 to 696 mm/9.84 to 27.40 inches
Specified value:
125 to 325.5 mm/4.92 to 12.82 inches
Cover width – specified value:
125 to 376.5 mm/4.92 to 14.82 inches
Spine
Base Spine Position
Next Button
190. 0
The specified position will align with the
scoring base line.
When you press the next button, you will go
to "4-6. Checking and Saving Settings"
( p.2-21).
