Operation
46 Operating Instructions 669 - 00.0 - 08/2019
2. Tilt the machine head (3) to the rear
The machine head (3) will be supported by the strap (2).
To erect the machine head:
1. Tilt the machine head (3) forwards.
2. Pull lever (1) back up.C
3. Carefully tilt the machine head (3) downwards
4.12 Folding down the tabletop (optional)
This option applies to the stand MG 56-2.
Fig. 21: Folding down the tabletop (1)
To fold down the tabletop:
1. Loosen the tabletop latch (1) located under the tabletop (2).
WARNING
Risk of injury from moving parts!
Crushing possible.
Hold the table top with both hands when pulling it
off.
(1) - Tabletop latch (2) - Tabletop
