Subclasses
Class 274
Sewing stitch type 301
Hook type Horizontal hook-small
Number of needles 1
Needle system 134, 797 or Sy 195 501
Needle thickness max. (dependent on E no.) [Nm] 70 - 120
Needle thread size max. 30/3
Max. stitch length
- forward [mm] 4
- reverse [mm] 4
Max. no. of stitches [min
-1
]5000
No. of stitches at delivery [min
-1
] 4800
Sewing foot stroke
- when lifted [mm] 6
Operating pressure [bar] 6
Air consumption [NL] 0,02
Length, width, height [mm] 500 x 175 x 380
Weight [kg] 36
Design voltage range [V/Hz] 1 x 190 - 240 V 50/60 Hz
Design voltage at delivery
[V/Hz] 1 x 230 V 50/60 Hz
Design power [kVA] 0,5
Noise
: Workplace-relevant emission value to DIN 45635-48-A-1-KL2
Lc [dB (A)] 83
Stitch length [mm] 3,2
No. of stitches [min
-1
]4.800
Material G1 DIN 23328 2-play
274 - 140342
GB
13
