4 Replacement Procedures 4.5 BATTERY PACK
4-22 [CONFIDENTIAL] PORTÉGÉ X30W-J, dynabook V*/VZ*/VC* Series Maintenance Manual (960-941)
Installing the BATTERY PACK
To install the BATTERY PACK, follow the steps below and refer to Figure 4-5.
CAUTION: The BATTERY PACK is a lithium ion battery, which can explode if not
properly replaced, used, handled or disposed of. For environmental reasons,
collect the spent BATTERY PACKs. Use only batteries recommended by our
company for replacements.
1. Set the BATTERY PACK to the COVER ASSY and secure it with the following
screws.
M24C S-THIN HEAD screw 2
2. Connect the BATTERY HARNESS to the connector CN8021 on the SYSTEM
BOARD.
3. Stick the INSU SQUARE in place.
To Next Page
